Global Telecom GLODU7243AB41
- SKU: GLODU7243AB41
$225.00 $399.00
+ $14.99 Tariff
Product Information
Titan4000 Cat15- 4x4 odu with 4 directional antennas B41 gain 12 dBi
Specifications
Specifications GLODU7243AB41
| Physical | |
| Dimensions | 305 mm (L) x 275 mm (W) x 142 mm (H) |
| Weight | < 3 kg |
| Power Consumption | < 15 W |
| Power Supply | 48 V / 0.5 A DC (Gigabit PoE) |
| Environmental | |
| Operating Temperature | -50°C to 75°C |
| Humidity | 95% max (non-condensing) |
| LTE Radio Interface | |
| Radio Access | 3GPP Release 13 |
| Category | 12/15 |
| Operation Mode | DL 4x4 MIMO / QAM256 Inter & Intra Band CA (4CC) |
| Frequency Band | TDD : B41/CBRS |
| Output Power | 23 dBm per Tx (2Tx) |
| Antenna Gain | B41 (4x4) 14 dBi (4 directional antennas) 4x4 configuration |
| User Interfaces | |
| Data Interface | 1 RJ45 10 / 100 / 1000 Mbps ETH |
| LED Indicators | PWR / SYS / NET / SIM / ETH / RF (5 signal intensity LEDs) |
| SIM Support | SIM card slot (2FF) |
| Industry Standards | |
| ITU | |
| 3GPP | Release 13 |
| IEEE | |
| IEEE 802.3 | 10Base Ethernet |
| IEEE 802.3u | Fast Ethernet |
| IEEE 802.3ab | Gigabit Ethernet |
| OTHERS | |
| Water Resistance | IP67 |
| Safety | FCC or CE |
