9Dot Terminal Unit with Integrated Controller with 4 Terminal Ports, 500W typ per port
- SKU: C-TER
$1,451.00
- Manufacturer: 9Dot
- Data Sheet: Download
Product Information
Terminal Unit with Integrated Controller with 4 Terminal Ports, 500W typ per port
C-TER is designed to supply power to devices directly on terminals. It consists of a single Rack unit that encloses the main control and interface system and output ports.
CPU:
- Fast software and firmware update
- Internal storage of each parameter
- Dynamic web interface
- Critical event warning and logging
- Internet connection via integrated WiFi
Design:
- SW / FW updates without service interruption
- Zero voltage drop from input to output and reduced self- consumption
- Input voltage detection with accurate measurement
- C-TER is designed to supply power to devices directly on terminals.
- It consists of a single Rack unit that encloses the main control and interface system and output ports.
Features:
- 2 input terminal blocks
- Flexible integration of the management system
- The web interface shows the voltage, temperature and instantaneous value of the load.
Specifications
Specifications C-TER
| Operating voltage | +21,4-57 VDC |
| Typical power | Up to 60A (up to 43A for single input terminal); 15A per output terminal |
| Power connector | 2x 16mm² cable terminals (input), 4x 16mm² cable terminals (output) |
| Ethernet connector | MGMT: 1x jack RJ45 shielded |
| GND connectors | 4 mm lug |
| Transmission speed | MGMT: 10Base; 100BaseT |
| LED indicator | Opt, status and alarm |
| Active protection | Reverse polarity protection (on input terminals) Against short circuit, over voltage, overload (on output terminals) 125 x 443 x 45 mm (without brackets); 125 x 483 x 45 mm (with brackets) |
| SPD | |
| Spark Over Voltage | 90V |
| Peak Surge Current | 15 kA |
| Modes of Protection | All Lines (1-2) Protected (L-L) and (L- G) |
| SPD Technology | 2 stages: TVS, GDT |
| Environmental | |
| Operating | -20°C to +50°C |
| Humidity | 5% - 90% non-condensing |
| Mechanical | |
| Dimensions (LxWxD) | 125 x 443 x 45 mm (4.92" x 17.44" x 1.77" inch) (without brackets); 125 x 483 x 45 mm (4.92" x 19.01" x 1.77" inch) (with brackets) |
| Weight | (4.40 lbs ) 2 kg |
| Material | Varnished Iron |
| Interface | |
| Interface | WiFi IEEE 802.11b/g/n Web interface, SSH, SNMP, API 10/100 BaseT RJ45, OPT button |
| Status indicator | Front: Opt LED (green), Status LED (blue), Alarm LED (red), 4x Port Led (RGB) |
| Compliance & Warranty | |
| Certifications | CE-FCC |
| Compliance RoHS | Yes |
| Warranty | Consult with the nearest distributor |
