Cambium Networks PTP 450i 5GHz End Connectorized (FCC)
- SKU: C050045B003B
$1,101.04
- Manufacturer: Cambium Networks
- Cambium Networks PTP 450i Fixed Wireless Backhaul Datasheet: Download
Product Information
Cambium Networks industry-leading 450 platform includes the all new PMP 450i and PTP 450i radios. The 450i product platform is the most scalable industrial-grade wireless broadband solution available.
Product Features- Ultra-wide band radios
- Rugged metal enclosure
- 2x2 OFDM MIMO radio capable of up to 300 Mbps per sector
- Input Voltage: 48-59V DC, 802.3at compliant
- Antenna Connection: 50ohm, N-Type
- Ethernet Interface: 100/1000BaseT, full duplex, rate auto negotiated (802.3 compliant)
Specifications
Specifications C050045B003B
| Channel Spacing | Configurable on 2.5 MHz increments |
| Frequency Range | 4900 to 5925 MHz |
| Channel Width | 5 / 10 / 20 MHz |
| MAC (Media Access Control) Layer | Cambium Networks proprietary |
| Physical Layer | 2x2 MIMO OFDM |
| Ethernet Interface | 100/1000BaseT, full duplex, rate auto negotiated (802.3 compliant) |
| Protocols Used | IPv4, UDP, TCP, IP, ICMP, Telnet, SNMP, HTTP, FTP |
| Network Management | HTTP, HTTPS, Telnet, FTP, SNMP v3 |
| VLAN | 802.1ad (DVLAN Q-inQ), 802.1Q with 802.1p priority, dynamic port VID |
| Maximum Deployment Range | Up to 58 to 400 miles minimum, depending on configuration |
| Latency | 3 to 5 ms, typical |
| GPS Synchronization | Yes, via Autosync (CMM3, CMM4) |
| Quality of Service | Diffserve QoS |
| Antenna Connection | 50Ω N-Type |
| Surge Suppression | EN6100-4-5:1.2us/50us, 500 V voltage waveform. Recommended external surge suppressor: Cambium Networks Model # C000000L033A |
| Mean Time Between Failure | > 40 years |
| Environmental | IP66, IP67 |
| Temperature / Humidity | -40°C to +60°C (-40°F to +140°F), 0 to 95% non-condensing |
| Weight | Approx. 2.0 kg (4.5 lbs) |
| Wind Survival | 190 km/h (118 mph) |
| Dimensions | 26.0 x 13.4 x 6.4 cm (1.25 x 5.25 x 3.25 ") |
| Power Consumption | 15 W typical, 15 W mac, 55 W max with Aux port PoE out enable |
| Input Voltage | 48-59 VDC, 802.3at compliant |
| Mounting | Wall or Pole mount with Cambium Networks Model # C050045B004A |
| Encryption | 56-bit DES, FIPS-197 128-bit AES |
| CE | EN 301 893 v.1.7.1 / EN 302 625 v.1.1.1 / EN 302 502 v.1.2.1 |
