ICT DIN Rail Mount 24V 360W DC Power Supply
- SKU: ICT360-24DIN
- Manufacturer: ICT
- Data Sheet: Download
Product Information
DIN rail mount 360 watt, 24 volt DC power supply with integrated low voltage disconnect. Functions standalone or with remote monitoring over Ethernet when used with ICT-DIN-PDU6 intelligent power distribution unit.
The ICT DIN Rail DC power supply with integrated battery charging and low voltage disconnect provides 360 watts of 48V or 24V DC output. It features wide-ranging AC input, low-noise FCC Class B emissions, temperature-compensated charging, adjustable charge current, and Form C alarm contacts.
The ICT DIN Series power supply can be paired with the ICT DIN Series power distribution unit for a fully remote monitored and managed DC power solution over Ethernet.
The ICT DIN Series is designed, manufactured and supported in North America to meet the need for wireless communications, broadband and other demanding DC power applications.
Product Features:- 360 Watt 24 Volt DC Output
- 120-240 Volt AC input
- 90 to 91% efficiency
- -30C to +60C operating temperature range
- Integrated Battery Charging and Low Voltage Disconnect
- Adjustable battery charge current
- Dual load connectors for installation flexibility
- Temperature compensated battery charging
- Form C alarm contacts
- Serial communications port for remote monitoring over Ethernet when used with ICT Intelligent DIN Power Distribution Unit
Specifications
Specifications ICT360-24DIN
| AC Input | |
| Nominal system voltage | 120/240 VAC |
| Input voltage range | 108-264 VAC |
| Power factor (typical) | 0.99 |
| Frequency | 50/60 Hz |
| Electrical | |
| Nominal DC output voltage | +/- 24 VDC |
| DC output voltage | 27.6 VDC |
| Power output | 360 W |
| Output current | 13.0 A |
| Efficiency (peak) | 91 % |
| Output ripple (rms) | 50 mV |
| Mechanical | |
| AC input connector | Terminal Block, #12 - #16 AWG |
| DC output connectors | Terminal Block, #12 - #14 AWG |
| Remote alarm connectors | Terminal Block, #22 - #26 AWG |
| Mounting | TS35 (EN50022) standard DIN rail mount |
| Cooling | Convection, fanless |
| Weight | 3.6 lbs /1.65 kg |
| Dimensions - H x W x L | 5.74 x 3.41 x 5.3 in. / 146 x 86.6 x 135 mm |
| Environmental | |
| Operating temperature range | -30oC to +60oC |
| Output derating | 2% / oC (Derate above 40oC) |
| Storage temperature | -45oC to +85oC" |
| Safety | EN 62368-1 |
| Emissions | EMC compliance with FCC Part 15, Class B, EN61000-6-1, EN61000-6-3, EN61000-3-2, RoHS, CE |
