Milesight MS-N5008-PE
- SKU: MS-N5008-PE
$785.00 $807.00
Product Information
NVR 8 Channel NDAA PoE
Specifications
Specifications MS-N5008-PE
| Video/Audio Input | |
| Network Video Input | 8-CH |
| Bandwidth Incoming | 80Mbps |
| Bandwidth Outgoing | 50Mbps |
| HDMI Output | 1-CH, Resolution: 3840x2160/30Hz, 1920x1080/60Hz, 1920x1080/50Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz HDMI Supports Audio Output |
| VGA Output | 1-CH, Resolution: 1920x1080/60Hz, 1920x1080/50Hz, 1280x1024/60Hz, 1280x720/60Hz, 1024x768/60Hz |
| Dual Stream | Support |
| Recording Resolution | 8MP/6MP/5MP/4MP/3MP/1080P/UXGA/720P/D1/VGA/CIF/QCIF |
| Synchronous Playback | 1*(30fps @8MP), 2*(30fps @6MP), 2*(30fps @5MP), 3*(30fps @4MP),4*(30fps @3MP),6*(30fps @1080P), 8*(30fps @720P) |
| Video Compression | H.265+/H.265(HEVC)/H.264+/H.264 |
| Audio Compression | G.711/AAC/G.722/G.726 |
| Sample Rate | 8KHz/16KHz |
| SATA | 2*SATA HDD(3.5”) |
| Capacity | Up to 20TB capacity for each HDD |
| Recording Type | Continuous, Event (Motion Detection, Alarm, VCA, Smart Analysis) |
| Snapshot Type | N/A |
| Playback Type | General Playback, Event Playback, Tag Playback, Split Playback, Picture Playback |
| Backup | Video Backup, Image Backup |
| Protocol | IPv4/IPv6, TCP, UDP, RTP, RTSP, RTCP, HTTP, HTTPS, DNS, DDNS, DHCP, NTP, SNTP, SMTP, SNMP, UPnP, NFS |
| Network Interface | 1*RJ45 10/100/1000Mbps |
| USB Interface | 2*USB 2.0 |
| Audio Input/Output | 1*RCA/1*RCA |
| Alarm Input/Output | 4-CH/1-CH |
| Interface | 8*RJ45 10/100Mbps |
| Power Output | ≤200W |
| Supported Standard | IEEE 802.3af/at |
| Compatibility | ONVIF, API |
| Advanced Function | ANR |
| ANPR | Support |
| Video Analysis | Region Entrance, Region Exiting, Advanced Motion Detection, Tamper Detection, Line Crossing, Loitering, Human Detection, People Counting, Object Left, Object Removed |
| Keyboard Control | Milesight Keyboard (MS-K01) |
| Power Supply | AC 100V~240V 50Hz~60Hz |
| Consumption | ≤9W(Without HDD, without enabling PoE) |
| Working Conditions | Temperature: -10℃~55℃ / Humidity: 10%~90% |
| Dimensions | Rack Mountable Chassis (1.0U Standard) 380mm(W)X317.6mm(D)X51.8mm(H) 14.96 x 12.50 x 2.03 inch |
| Weight | 2.6Kg (5.73 lbs) |
| Warranty | 3/5 Years |
