Product Information
Ubiquiti Networks UVC Micro, G3
Specifications
Specifications UVC-G3-MICRO
| Dimensions Body Base | Ø 51.38 x 41.97 mm (Ø 2.02 x 1.65") Ø 36 x 17.3 mm (Ø 1.42 x 0.68") |
| Weight Body Base | 65 g (2.29 oz) 31 g (1.09 oz) |
| Networking Interface | 802.11 a/b/g/n, 2.4 GHz/5 GHz Dual-Band Wi-Fi |
| Sensor | 1/3" 4-Megapixel Sensor with WDR |
| Lens | EFL 2.7 mm, f/2.2 |
| Night Mode | IR LEDs with Removable IR Cut Filter, Built-in Light Sensor |
| Microphone | Yes (with Microphone Volume Control) |
| Button | Factory Reset Button |
| Power Method | 24V Passive PoE |
| Power Supply | AC Adapter (Included), or Instant PoE Adapter (Included) and 802.3af PoE Switch |
| Maximum Power Consumption | IR LEDs On: 3.5W IR LEDs Off: 2W |
| Mounting | Magnetic Base/Wall/Table |
| Operating Temperature | 0 to 35° C (32 to 95° F) |
| Operating Humidity | 20 - 90% Noncondensing |
| VIDEO | |
| Video Compression | H.264 |
| Resolution | 1080p Full HD (1920x1080) |
| Maximum Frame Rate | 30 FPS |
| Image Settings | Flip, Brightness, Contrast, AE Mode (50/60 Hz), WDR, Hue, Infrared, Sharpness, Saturation, Noise Reduction |
| Viewing Angle LDC Off LDC On | 124° (H), 65° (V), 150° (D) 92° (H), 6° (V), 100° (D) |
| Supported UniFi Video Version | UniFi Video 3.8 (or Newer) |
