Cambium Networks ePMP 5GHz Force 200AR5-25 High Gain Radio (FCC)

The ePMP Force 200 high gain integrated solution enhances range and improves throughput in high interference environments. ePMP Force 200 is a completely redesigned solution from Cambium Networks that combines a highly integrated, high performance radio with a high gain dish antenna.

The radio supports a gigabit Ethernet interface in order to provide maximum throughput. The solution brings wireless broadband connectivity to customers over longer distances and provides a superior return on investment.

• Designed to operate in high interference environments and provides superior throughput of over 200 Mbps of real user data
• Configurable Modes of operation ensure robust adaptivity to both symmetrical and asymmetrical traffic while providing high performance and round-trip latency as low as 2 – 3ms
• QoS management offers an outstanding quality for triple play services – VoIP, video and data and provides three levels of traffic priority
• Long deployment range is enabled by a high gain antenna combined with 30 dBm of transmit power
• This platform can be configured as a Subscriber Module or a high gain PTP radio

• 25dBi peak gain
• 10W maximum, 5W typical power consumption
• 10V to 30V input voltage
