Product Information
The PTP 820S licensed microwave radio from Cambium Networks is capable of 2048 QAM with ACM and supports 6-38GHz.
Product Features- Protection: 1+1 HSB
- QPSK to 2048 QAM w/ACM
- Advanced Frequency Reuse (AFR)
- Maximum Power Consumption: 6-11GHz: 35W; 13-38GHz: 42W
- Dimensions: 230mm(H), 233mm(W), 98mm(D)
- Standard Input: −48VDC
Specifications
Specifications C180082B012A
| Frequency Range | Wide 18GHz |
| Configurations | 1+0, 1+1 HSB |
| Radio Features | Protection: 1+1 HSB, High spectral utilization: QPSK to 2048 QAM w/ACM |
| Transport Technology | All packet |
| TDM Interface | None |
| Modulation | QPSK to 2048 QAM w/ACM |
| L2 Capacity | 605Mbps |
| Capacity with Multi-Layer Compression | 833Mbps |
| Configuration | 1+0, 1+1 HSB |
| LOS MiMO | No |
| XPIC | No |
| Management Interface | 1 x 10/100 Base-T |
| External Alarm | None |
| Environment | -27.4 to 131deg F (-33 to 55deg C) |
| Power Input | -48VDC |
| PoE Injector Power Input | -48VDC or +24VDC |
| Power Consumption | 32W |
