MikroTik Chateau PRO ax (US)
- SKU: H53UiG-5HaxQ2HaxQ-US
$199.00
- Manufacturer: MikroTik
- Data Sheet: Download
Product Information
H53UiG-5HaxQ2HaxQ-US
Specifications
Specifications H53UiG-5HaxQ2HaxQ
| CPU | Quad-Core IPQ-8072A 2208 MHz |
| CPU architecture | ARM 64bit |
| Size of RAM | 1 GB |
| RAM type | DDR3 |
| Storage | 128 MB, NAND |
| Number of 1G Ethernet ports | 5 |
| USB port | 1 (3.0 type A) |
| Switch chip model | IPQ-8072 |
| Wireless interface model | QCN-5024 (2.4 GHz), QCN-5054 (5 GHz) |
| Wireless | 2.4 GHz 802.11b/g/n/ax, 5 GHz 802.11a/n/ac/ax |
| Antenna gain | 2.4 GHz - 5 dBi, 5 GHz - 6 dBi |
| Dimensions | 240 x 156 x 44 mm 9.44" x 6.14" x 1.73" inch |
| Operating system | RouterOS v7, License level 6 |
| Operating temperature | -40°C to +70°C |
| Powering | |
| Number of DC inputs | 1 |
| DC jack input Voltage | 18-57 V |
| PoE-Out | Passive PoE up to 57 V (Ether5) |
| Max out per port output (input < 30 V) | 600 mA |
| Max out per port output (input > 30 V) | 500 mA |
| Max power consumption without attachments | 18 W |
| Max power consumption | 55 W |
