RF elements TwistPort Adaptor For Rocket 5ac Prism & AirFiber 5X-HD (Tariff)
- SKU: TPA-PAF
$62.00
+ $20.48 Tariff
- Manufacturer: RF Elements
- Data Sheet: Download
Product Information
RF elements TwistPort Adaptor for Rocket 5ac Prism and the AirFiber 5X-HD.
Specifications
Specifications TPA-PAF
| Antenna Connection | TwistPort - Quick Locking Waveguide Port |
| Radio Connection | 2x Slide-On RP-SMA and 1x RP-SMA for GPS |
| Materials | Insert - Aluminium Alloy Adaptor - UV stabilized and weather resistant ABS plastic |
| Flame Rating | UL 94 HB |
| Temperature | -40°C to +60°C (-40°F to +140°F) |
| Wind Survival | 160 km/h |
| Weight | 0.34 Kg / 0.75 lbs – single unit 0.52 Kg / 1.14 lbs – single unit incl. package 11.2 Kg / 24.7 lbs – carton (20 units) |
| PERFORMANCE | |
| Frequency Range | 5180 - 6400 MHz |
| Polarization | Dual Linear H + V |
| VSWR Max | 1.8 |
| Impedance | 50 Ohm |
| COMPATIBLE WIRELESS PLATFORMS | |
| RF elements® | any TwistPort™ Antenna |
| Ubiquiti Networks® | Rocket® Prism 5AC, Rocket® Prism 5AC Gen2 airFiber® 5X, airFiber® 5X-HD |
