TP-Link AXE5400 Tri-Band Wi-Fi 6E Bluetooth PCI Express Adapter
- SKU: CPE210
$44.99
Product Information
2.4 GHz 300 Mbps 9 dBi Outdoor CPE PORT: 1× 10/100 Mbps Shielded Ethernet Port SPEED: 300 Mbps at 2.4 GHz FEATURE: 9 dBi, 5+ km, IPX5 Weatherproof, Passive PoE, MAXtream TDMA, Centralized Management, Spectrum Analyzer, AP/Client/AP Router/AP Client Router/Repeater/Bridge mode
Specifications
Specifications CPE210
| Processor | Qualcomm Atheros 560MHz CPU, MIPS 74Kc |
| Memory | 64MB DDR2 RAM, 8MB Flash |
| Interface | 1 10/100Mbps Shielded Ethernet Port (LAN0,Passive PoE in) 1 10/100Mbps Shielded Ethernet Port (LAN1, Passive PoE Passthrough) 1 Grounding Terminal 1 Reset Button |
| Power Supply | Passive Power over Ethernet via LAN0 (+4,5pins; -7,8pins) Voltage range: 16-27VDC |
| Power Consumption | 10.5 Watts Max |
| Dimensions ( W x D x H ) | 224 x 79 x 60 mm |
| Antenna Type | Built-in 9dBi 2x2 Dual-polarized Directional Antenna Beam Width: 65° (H-Plane) / 35° (E-Plane) |
| Protection | 15KV ESD Protection 6KV Lightning Protection |
| Enclosure | Outdoor ASA stabilized plastic material IPX5 waterproof Certification |
| Wireless Standards | IEEE 802.11b/g/n (with Pharos MAXtream disabled) |
| Proprietary Protocol | TDMA Mode (with Pharos MAXtream enabled) |
| Wireless Speeds | Up to 300Mbps (40MHz,Dynamic) Up to 144.4Mbps (20MHz,Dynamic) Up to 72.2Mbps (10MHz,Dynamic) Up to 36.1Mbps (5MHz,Dynamic) |
| Frequency | 2.4~2.483GHz |
| Transmission Power | 27dBm/500mw (Adjustable power by 1dBm) |
