TP-Link Archer AX73
- SKU: Archer AX73
$179.99
Product Information
AX5400 Dual-Band Gigabit Wi-Fi 6 Router
Specifications
Specifications Archer AX73
| Hardware | |
| Antennas | 6× High-Performance Antennas |
| Ethernet Ports | 1× Gigabit WAN Port + 4 × Gigabit LAN Ports |
| USB Ports | 1× USB 3.0 Port |
| Dimensions | 10.7 × 5.8 × 1.9 in (272.5 × 147.2 × 49.2 mm) |
| Wireless | |
| Wireless | 4804 Mbps (5 GHz, 11ax) + 574 Mbps (2.4 GHz, 11ax), compatible with 11a/b/g/n/ac Wi-Fi standards |
| Frequency | 2.4 GHz and 5 GHz |
| Transmit Power | CE: <20dBm (2.4GHz); <23dBm (5.15GHz~5.35GHz); <30dBm (5.47GHz~5.725GHz) FCC: <24dBm (5.25GHz~5.35GHz&5.47GHz~5.725GHz ) <30dBm (2.4GHz &5.15GHz~5.25GHz&5.725GHz~5.825GHz) |
| Reception Sensitivity | 2.4GHz: 11ac VHT20 MCS0:-94.5dBm, 11ac VHT20 MCS8:-72.5dBm, 11ac VHT40 MCS0:-92.5dBm, 11ac VHT40 MCS9:-69.5dBm, 11ax HE20 MCS0:-95dBm, 11ax HE20 MCS11:-64.5dBm, 11ax HE40 MCS0:-92.5dBm, 11ax HE40 MCS11:-62dBm 5GHz: 11ac VHT20 MCS0:-97dBm, 11ac VHT20 MCS8:-74dBm, 11ac VHT40 MCS0:-95dBm, 11ac VHT40 MCS9:-70dBm, 11ac VHT80 MCS0:-91.5dBm, 11ac VHT80 MCS9:-66dBm, 11ac VHT160 MCS0:-86dBm, 11ac VHT160 MCS9:-61dBm, 11ax HE20 MCS0:-95dBm, 11ax HE20 MCS11:-64dBm, 11ax HE40 MCS0:-91.5dBm, 11ax HE40 MCS11:-62dBm, 11ax HE80 MCS0:-88dBm, 11ax HE80 MCS11:-58dBm, 11ax HE160 MCS0:-85.5dBm, 11ax HE160 MCS11:-55dBm |
| Wireless Function | Enable/Disable Wireless Radio, WMM, Wireless Statistics |
| Wireless Security | WPA/WPA2-Personal, WPA2/WPA3-Personal, WPA/WPA2-Enterprise |
| Software | |
| WAN Type | Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access) |
| Management | Access Control, Local Management, Remote Management |
| DHCP | Server, DHCP Client List, Address Reservation |
| NAT Forwarding | Port Forwarding, Port Triggering, UPnP, DMZ |
| Dynamic DNS | DynDns, NO-IP, TP-Link |
| Access Control | Parental Controls, Local Management Control, Host List, White List, Black List |
| Firewall Security | SPI Firewall, IP and MAC Address Binding |
| Protocols | IPv4, IPv6 |
| USB Sharing | Supports Samba(Storage)/FTP Server/Media Server |
| Guest Network | 2.4 GHz Guest Network, 5 GHz Guest Network |
| VPN Server | OpenVPN, PPTP VPN |
| Others | |
| Certification | FCC, CE, RoHS |
| System Requirements | Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS, NetWare, UNIX or Linux Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other Java-enabled browser Cable or DSL Modem Subscription with an internet service provider (for internet access) |
| Environment | Operating Temperature: 0℃~40℃ (32℉ ~104℉) Operating Humidity: 10%~90% non-condensing |
