TP-Link 18-Port Gigabit Easy Smart Switch with 16-Port PoE+
- SKU: TL-SG1218MPE
$189.99
Product Information
18-Port Gigabit Easy Smart Switch with 16-Port PoE+ PORT: 16× Gigabit PoE+ Ports, 2× Gigabit Non-PoE Ports, 2× Combo Gigabit SFP Slots SPEC: 802.3at/af, 250 W PoE Power, 1U 19-inch Rack-mountable Steel Case FEATURE: PoE Auto Recovery, MTU/Port/Tag-based VLAN, QoS, IGMP Snooping, Web/Utility Management, Plug and Play
Specifications
Specifications TL-SG1218MPE
| Interfaces | 16 10/100/1000Mbps RJ45 Ports 2 Gigabit SFP Slots |
| PoE | |
| PoE Standard | 802.3 af/at |
| PoE Ports | 16, up to 30W |
| PoE Power | Budget 192W |
| Performance | |
| Switching Capacity | 36Gbps |
| Packet Forwarding Rate | 23.8Mpps |
| Max Address Table | 8K |
| Packet Buffer | 4.1Mbit |
| Jumbo Frame | 9KB |
| Physical & Environment | |
| Power Supply | 100-240V AC, 50/60Hz |
| Maximum Power Consumption (220V/50Hz) | 18.73W (220V/50Hz. no PD connected) 217.22W (220V/50Hz. with 192W PD connected) Maximum Heat |
| Dissipation | 63.89 BTU/h (no PD connected) 741.15 BTU/h (with 192W PD connected) |
| Dimensions (W×D×H) | 17.3 × 7.1 × 1.7 in. (440 × 180 × 44 mm) |
| FAN Quantity | 2 |
| Operating Temperature | 0°C~50°C (32°F~122°F) |
| Storage Temperature | -40°C~70°C (-40°F~158°F) |
| Operating Humidity | 10% ~ 90%RH, non-condensing |
| Storage Humidity | 5%~90%RH, non-condensing |
| Certification | CE, FCC |
| Software Features | |
| L2 Features | • Link Aggregation - Static link aggregation - Up to 8 aggregation groups and up to 4 ports per group • Loopback Detection • Port Statistics • Cable Test • Flow Control • Mirroring - Port Mirroring - Ingress/Egress/Both |
| IGMP Snooping | • IGMP v1/v2/v3 Snooping • 128 Max Multicast Entries |
| VLAN | • 802.1Q VLAN • Port Based VLAN • MTU VLAN |
| QoS | • Port Based, 802.1p Based, 802.1p CoS/ DSCP priority • Bandwidth Control - Ingress Rate/Egress Rate/Both • Storm Control - Broadcast/Multicast/Unknown-Unicast Control |
