Product Information
300Mbps Wireless N Access Point
Specifications
Specifications TL-WA801N
| Interface | 1× 10/100 M Ethernet Port(RJ45) Support Passive PoE |
| Button | Power On/Off Button, WPS Button, Reset Button |
| External Power Supply | 9VDC / 0.6A |
| Wireless Standards | IEEE 802.11n, IEEE 802.11g, IEEE 802.11b |
| Dimensions ( W x D x H ) | 7.1 × 5.1 × 1.4 in (182 × 130 × 36 mm) |
| Antenna Type | 2 Fixed Omni-Directional Antennas |
| Frequency | 2.4 GHz |
| Signal Rate | 300 Mbps at 2.4 GHz |
| Reception Sensitivity | 11g 6Mbps: -90dBm, 11g 54Mbps: -77dBm, 11n HT20 MC7: -73dBm, 11n HT40 MC7: -70dBm, Transmit Power, < 20dBm |
| Wireless Modes | AP Mode, Multi-SSID Mode, Client Mode, Range Extender Mode |
| Wireless Functions | Enable/Disable Wireless Radio, WMM, Short GI, AP, Isolation, Wireless Statistics, Throughput Monitor |
| Wireless Security | WEP, WPA/WPA2, WPA/WPA2-PSK encryptions |
| Quality of Service | WMM |
| Management | SNMP |
| Advanced Functions | Up to 30 meters Passive PoE is supported |
| Environment Operating | Temperature: 0°C~40°C (32°F ~104°F) Storage Temperature: -40°C~70°C (-40°F ~158°F) Operating Humidity: 10%~90% RH Storage Humidity: 5%~90% RH |
