Tejas Networks TJ2100N-12B
- SKU: TJ2100N-12B
$55.00 $85.00
+ $11.88 Tariff
- Manufacturer: Tejas Networks
- Data Sheet: Download
Product Information
1GE port ONT : TJ2100N-ONT12B : 1x10/100/1000 with Power Adapter for US
Specifications
Specifications TJ2100N-12B
| Supported bands | R9, TDD Mode |
| GPON Interface | SC/APC connector Transmission: ITU-T G.984 | Optical module: Class B+ Optical transmit power +0.5 to +5dBm and Receive sensitivity of –28dBm. Upstream and Downstream FEC |
| Ethernet | Meets 802.3 specifications 1x10/100/1000Mbps RJ-45 connector Half-duplex & full-duplex operation 10/100/1000Mbps auto-negotiation MDI/MDIX auto detection |
| Layer 3/4 hardware NAT/nAPT | Support 4K/8K/16K/32K flow based connections | Port/VLAN bridging | IPV4/IPV6 flow routing for policy rate |IPoE/DHCP/PPPoE/DS-Lite/PPTP/L2TP WAN hardware forward |
| Layer 2 capabilities | Non-Blocking wire speed reception and transmission | Supports source and destination MAC address filtering |
| Environmental | Operating Temperature: 0 ºC to 45 ºC Altitude: 4,000m operations : Humidity: 5 to 93% RH non-condensing |
| Management | G.988(OMCI), TR69, SNMP |
