Ubiquiti UniFi 10G Multi-WAN Gateway Pro (US)
- SKU: UXG-Pro-US
$499.00
Product Information
Dual-WAN security gateway designed to protect medium to large-sized networks with enterprise-class firewall configuration and threat management features.
Specifications
Specifications UXG-Pro
| Mechanical | |
| Dimensions | 442.4 x 43.7 x 285.6 mm (17.42 x 1.72 x 11.24") |
| Weight | 3.42 kg (7.54 lb) |
| Enclosure materials | Front panel: aluminum CNC Top cover/base: SGCC steel |
| Hardware | |
| Processor | Quad-core ARM® Cortex®-A57 at 1.7 GHz |
| Memory information | 2 GB DDR4 |
| Management interface | Ethernet |
| Networking interface | LAN: (1) 1 GbE RJ45 port (1) 10G SFP+ port WAN: (1) 1 GbE RJ45 port (1) 10G SFP+ port |
| LCM display | (1) 1.3" touchscreen Bootup animation: bootup in progress Firmware upgrade icon: firmware upgrading |
| Button | Factory reset |
| Power method | |
| US | (1) Universal AC input, 125VAC, 2.7A max., 60 Hz (1) RPS DC input, 11.5VDC, 2.87A |
| Worldwide | (1) Universal AC input, 200-240VAC, 1.7A max., 50/60 Hz (1) RPS DC input, 11.5VDC, 2.87A |
| Power supply | AC/DC, internal, 50W |
| Max. power consumption | 30W |
| ESD/EMP protection | Air: ± 15 kV, contact: ± 8 kV |
| Operating temperature | -10 to 40° C (14 to 104° F) |
| Operating humidity | 5 - 95% noncondensing |
| Certifications | CE, FCC, IC |
| LEDs | |
| AC outlet/ RPS | Blue |
| Ethernet | Green/amber |
| SFP+ | White/green |
