Product Information
The Alta Labs AP6 Access Point has a compact design that allows for easy integration into corporate, commercial, and residential spaces.
- Superior Range and Performance
- Scalable Cloud-Based Management
- AltaPass Multi-Password Technology
- Mobile App
- DPI Engine
- High-Performance WiFi 6
- Hotspot Functionality
- On-The-Fly Changes and Scanning
- SSID Broadcasting Flexibility
Specifications
Specifications AP6
| WIFI 6 | Yes |
| BLUETOOTH FOR EASY ADOPTION | Yes |
| CONTENT FILTERING | Yes |
| MAX WIFI THROUGHPUT | 2.4 Gbps |
| POWER | PoE+ |
| 4096-QAM | No |
| Dimensions | 190mm (7.5” ) x 125mm (4.9”) 32mm (1.25”) |
| Weight | 0.4 kg (0.9 lbs) |
| Enclosure Material | Top Cover: Polycarbonate Bottom Cover: Milled Aluminum |
| Mount Material | Ceiling/Wall: Polycarbonate Drop Ceiling: Steel |
| Weatherproofing | N/A |
| HARDWARE | |
| Network Interface | Ethernet, WiFi, Bluetooth |
| Management Interface | (1) GbE RJ45 Port |
| Button(s) | Reset/Factory Reset |
| LED | Blue, White |
| Power Method | PoE+ |
| Power Supply | PoE+ enabled network switch 48V, 0.5A PoE adapter (optional) |
| Supported Voltage Range | 42.5 - 57V DC |
| Maximum Power Consumption | 20W |
| Maximum Transmit Power | 2.4 GHz: 23 dBm @2NSS 5 GHz: 23 dBm @2NSS |
| MIMO | 2.4 GHz: 2 x 2 5 GHz: 2 x 2 |
| Throughput Rate | 2.4 GHz: Up to 573 Mbps 5 GHz: Up to 2.4 Gbps |
| Antenna Gain | 2.4 GHz: Up to 4.0 dBi 5 GHz: Up to 4.1 dBi |
| Mounting | Wall, ceiling, drop-ceiling, table top |
| Operating Temperature | -30 to 60° C (-22 to 140° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Certifications | CE, FCC, IC |
| WiFi Standards | 801.11a/b/g/n/ac/ax WiFi4/WiFi5/WiFi6 |
| Roaming | 802.11r/k/v |
| Wireless Security | WPA-PSK, WPA-Enterprise (WPA2/WPA3) |
| Multi-BSSID | Supported |
| VLAN | 802.1Q |
| Advanced QoS | 802.11e |
| Guest Traffic Isolation | Supported |
| Concurrent Clients | 300+ |
| Zero Wait DFS | Yes |
| Intelligent WiFi Scheduling | Yes |
| Painless Hotspot Setup | Yes |
| Scale From Home to SMB to Stadium | Yes |
| Seamless Per-Client Settings | VLAN, Device Type, Rate Limit, Hotspot/Schedule Exception |
| SUPPORTED DATA RATES | |
| 802.11a/g | 6 Mbps to 54 Mbps |
| 802.11b | 1 Mbps to 11 Mbps |
| 802.11n | 6.5 Mbps to 300 Mbps (Up to MCS 15) |
| 802.11ac | 6.5 Mbps to 1.9 Gbps (Up to MCS 9) |
| 802.11ax | 2.4 GHz: Up to 573 Mbps 5 GHz: 6.5 Mbps to 2.4 Gbps (Up to MCS 11) |
