ALTA Labs 8-Port Layer 2 60W PoE Managed Enterprise Network Switch
- SKU: S8-POE
$149.00
- Manufacturer: ALTA Labs
- Data Sheet: Download
Product Information
ALTA Labs S8, POE, 8 Port POE switch
Specifications
Specifications S8-POE
| Dimensions | 25.7 x 91 x 180 mm (1 x 3.6 x 7.1") |
| Weight | .38 kg (.83 lbs) |
| Material Type | Injection Molded Plastic |
| Material Finish | Matte |
| Color | White |
| Ports | |
| Interface ports | (8) 10/100/1000 Mbps |
| SFP/SFP+ | None |
| Switching Capacity | 16 Gbps |
| Non‑blocking Throughput | 8 Gbps |
| Forwarding Rate | 11.9 Gbps |
| PoE Budget/Max | 60 Watts |
| PoE Supply | 30 Watts per port |
| Per Port PoE | (4) 802.3at PoE+ |
| Non‑PoE Ports | -4 |
| LEDS | |
| PoE | Orange |
| Network | Orange: 10/100 Mbps, Blue: 1000Mbps |
| SFP/SFP+ | None |
| HARDWARE | |
| Packet Buffer | 4.1 Mbit |
| Mac Table Size | 8 K |
| Energy Efficient Ethernet | Yes |
| Management | Factory reset button |
| Bluetooth | Yes, Setup |
| POWER | |
| Max Power Consumption w/o PoE | 8 Watts |
| Max Power Consumption Full PoE | 68 Watts |
| Output | PoE+, 54VDC, 0.6A Max. |
| Power Supply | Universal AC, 100 ‑ 240VAC 50‑60Hz External |
| RJ45 Port Surge Protection | 12kV for ESD ‑ contact, 25kV for ESD ‑ Air |
| ENVIRONMENTAL | |
| Mounting | Locking Wallmount |
| Operating Temperature | ‑5 to 50° C (23 to 122° F) |
| Operating Humidity | 10 to 90% Noncondensing |
| IP Rating | None |
| EMI Rating | EMI Class‑B with 3dB margin |
| Cooling Fan | No (Fanless cooling) |
| Certifications | CE, FCC, IC |
