Cambium Networks ePMP 5GHz Force 300-19 (IC)
- SKU: C050900C801A
$233.03
- Manufacturer: Cambium Networks
- Data Sheet: Download
Product Information
Service providers face ever-increasing demand for capacity in a limited amount of spectrum. The Force 300 series of subscriber modules (SM) meets this demand offering high performance and low latency across both point-to-multipoint and point-to-point deployments.
Combining the latest 802.11ac Wave 2 technology and the field proven scalable performance of ePMP, the Force 300-19 delivers up to 600Mbps of capacity. The Force 300-19 is a powerful yet affordable subscriber module compatible with the ePMP 3000 Access Point and using the forward compatibility features also interoperates with the ePMP 2000 to ease the migration into the 802.11ac Wave 2 technology.
Product Features- Up to 600 Mbps capacity and latencies as low as 2 ms when using ePTP technology
- Proven air interface on top of 802.11ac Wave 2 technology
- Interoperability with the 3000, which uses MU-MIMO to achieve 1.2 Gbps per sector by transmitting to two Force 300 SM’s simultaneously
- Interoperability with 3000L, MP 3000 MicroPOP and backward compatibility with the 2000 and 1000
- Multiple levels of QoS (Quality of Service) for voice, video and data applications supporting a wide variety of service packages for both residential and enterprise users
- Security features meeting the requirements of enterprise, industrial, government and service provider users
- Management by Cambium Networks cnMaestro™ element management system for easy provisioning, monitoring and upgrades
- Network planning with LINKPlanner and cnHeat
Specifications
Specifications C050900C801A
| Channel Spacing | Configurable in 5 MHz increments |
| Frequency Range | Wide Band Operation 4910 - 5970 MHz (Note: Allowable frequencies and bands are dictated by individual country regulations.) |
| Channel Width | 20 / 40 / 80 |
| MAC Media Access Control Layer | Cambium |
| Proprietary Physical Layer | 802.11ac Wave 2 (2x2 MIMO/OFDM) |
| Ethernet Interfaced | 10/100/1000 BaseT, Compatible with Cambium PoE & Standard PoE pin-outs |
| Protocols Used | IPv4/IPv6 (Dual Stack), UDP, TCP, ICMP, SNMPv2c, NTP, STP, IGMP, SSH |
| Network Management | IPv4/IPv6, HTTPs, SNMPv2c, SSH, Cambium Networks CnMaestro |
| VLAN | 802.1Q with 802.1p priority |
| ARQ | Yes |
| Nominal Receive Sensitivity (w/FEC) @20 MHz Channel | MCS0 = -89 dBm to MCS8 (256 QAM-3/4) = -68 dBm (per chain) |
| Nominal Receive Sensitivity (w/FEC) @40 MHz Channel | MCS0 = -87 dBm to MCS9 (256 QAM-5/6) = -66 dBm (per chain) |
| Nominal Receive Sensitivity (w/FEC) @80 MHz Channel | MCS0 = -84 dBm to MCS9 (256 QAM-5/6) = -61 dBm (per chain) |
| Modulation Levels (Adaptive) | MCS0(BPSK) to MCS9 (256 QAM-5/6) |
| Transmit Power Range | 0 to +28 dBm (combined up to the regional EIRP limit) (1 dB interval) |
| Surge Suppression | 1 Joule Integrated (C000000L065A - 30V Gigabit surge suppressor is recommended for optimum protection) |
| Environmental | IP55 |
| Temperature | -30°C to +60°C (-22°F to +140°F) |
| Weight | 1.45 kg (3.2 lbs.) (includes mounting bracket) |
| Wind Survival | 180 km/hour (112 mi/hour) |
| Dimensions | 27.8 x 27.8 x 4.5 cm (10.9 x 10.9 x 1.8 in) without mounting bracket |
| Pole Diameter Range | 1 – 1.6 in (2.5 – 4.1 cm) with included clamp; up to 2.25 in (5.7 cm) with larger clamp |
| Power Consumption | 12 Watts |
| Input Voltage | Passive POE (30 VDC Nominal); 14-30 VDC range |
| Encryption | 128-bit AES (CCMP mode) |
| FCCID | Z8H89FT0048 |
| Industry Canada Cert | 109W-0048 |
| CE | EN 301 893 V2.1.1 (5.4 GHz), EN 302 502 V2.1.1 (5.8 GHz)** |
