Cambium Networks ePMP 5GHz Force 300 CSM (FCC)

(0)No Reviews yet
  • SKU: C058910C122A
$320.07
+ $14.40 Tariff
  • Manufacturer: Cambium Networks
  • Data Sheet: Download

376 In Stock

376 in stock
Kalama WA
18 In stock
Illinois - West Chicago
357 In stock
College Station - TX
1 In stock

Product Information

Wireless service providers and enterprises around the globe are challenged to deliver reliable connectivity in overcrowded RF environments. As spectrum increasingly becomes a scarce commodity, finding the right broadband connectivity solution is vital for all low and high density types of deployments.

Cambium Networks resolves this challenge with a breakthrough technology solution that delivers superior performance, resiliency and reach in the most congested environments. Combining the latest 802.11ac Wave 2 chipset and the field proven TDD MAC of ePMP, the Force 300 CSM offers a versatile solution enabling a wide variety of deployment models.

Product Features
  • Designed to operate in high interference environments and provides superior throughput of over 500Mbps
  • Configurable modes of operation ensure robust adaptivity to both sympetrical and asymmetrical traffic while providing high performance and round-trip latency as low as 3-5 ms
  • Offers deployment versatility with options for parabolic dishes and compatibility with the RF Elements Twistport ePMP adaptor
Product Specifications
  • Frequency Range: 4910MHz - 6135MHz
  • Weight: 0.5kg (1.1lb) Includes mounting bracket
  • Power Consumption:12W

Specifications

Specifications C058910C122A

SPECTRUM
Channel SpacingConfigurable on 5 MHz increments
Frequency RangeWide Band Operation 4.910 – 5.970 MHz (Note: Allowable frequencies and bands are dictated by individual country regulations.)
Channel Width20 | 40 | 80 MHz
INTERFACE
MAC (Media Access Control) LayerCambium Proprietary
Physical Layer2x2 MIMO/OFDM
Ethernet Interfaced10/100/1000 BaseT, Compatible with Cambium PoE & Standard PoE pinouts
Protocols UsedIPv4/IPv6 (Dual Stack), UDP, TCP, ICMP, SNMPv2c, NTP, STP, IGMP, SSH
Network ManagementIPv4/IPv6, HTTPs, SNMPv2c, SSH, Cambium Networks cnMaestro™
VLAN802.1Q with 802.1p priority
PERFORMANCE
ARQYes
Nominal Receive Sensitivity (w/FEC) @20 MHz ChannelMCS0 = -89 dBm to MCS8 (256 QAM-3/4) = -66 dBm (per chain)
Nominal Receive Sensitivity (w/FEC) @40 MHz Channel MCS0 = -87 dBm to MCS9 (256QAM-5/6) = -64 dBm (per chain)
Nominal Receive Sensitivity (w/FEC) @80 MHz ChannelMCS0 = -84 dBm to MCS9 (256QAM-5/6) = -59 dBm (per chain)
Modulation Levels (Adaptive)MCS0(BPSK)to MCS9 (256QAM5/6)
Transmit Power Range0 to +29 dBm (combined, to regional EIRP limit) (1 dB interval)
PHYSICAL
Surge Suppression1 Joule Integrated; Optional 30V Surge Suppressor (C000000L065A)
EnvironmentalIP67
Temperature-22°F to +140°F (-30°C to +60°C)
Weight0.46 kg (1.0 lbs.)
Wind Survival180 km/hour (112 mi/hour)
