MikroTik Outdoor PoE Desktop Router for RB5009 Series
- SKU: RB5009UPr+S+IN
Product Information
This version of the RB5009 has Gigabit Ethernet, 2.5 Gigabit Ethernet, and a 10 Gigabit SFP+ cage for fiber connectivity. It has the speed, the power, and the durability. It also has PoE-in & PoE-out on all eight Ethernet ports. Combined with the 2-pin connector and the DC jack, you are getting 10 separate ways of powering. Dual redundant power supplies would usually take your uninterrupted uptime to the next level.
All power options support a wide voltage range of 24V to 57V. However, you can not mix the voltages. If you are using PoE-out to power other devices, the board will choose the source with the highest voltage (DC jack or the 2-pin connector) to power those.
Each PoE-out port can supply up to 25W of power. All the ports combined are limited to 130W, which should be enough for most setups. You can specify maximum available power from your power sources manually, if necessary.
Specifications
Specifications
| CPU | 88F7040 1.4 GHz |
| CPU architecture | ARM 64bit |
| CPU core count | 4 |
| Size of RAM | 1 GB |
| RAM type | DDR4 |
| Storage | 1 GB, NAND |
| Number of 1G Ethernet ports | 7 |
| Number of 2.5G Ethernet ports | 1 |
| Number of 10G SFP+ ports | 1 |
| USB port | 1 (3.0 type A) |
| Operating system | Only v7 RouterOS |
| Switch chip model | 88E6393 |
| Dimensions | 220 x 125 x 22 mm 8.66 x 4.92 x 0.86 in |
| Operating temperature | -40°C to +60°C |
| PoE-in | 802.3af/at |
| PoE-Out | 802.3af/at |
| PoE-Out ports | Ether1 - Ether8, max out per port output (input < 30 V): 640 mA,max out per port output (input > 30 V): 420 mA |
| Smart PoE | Controller |
| Max total out | 2.59 A |
| Total output power | 130 W |
| Total output current | 2.28 A |
| Number of DC inputs | 3 |
| Supported input voltage | 24-57 V (PoE in) 24-57 V (DC jack) 24-57 (2-pin terminal) |
| Power adapter nominal voltage | 48 V |
| Power adapter nominal current | 2 A |
| Max power consumption (without attachments) | 15 W |
| Max power consumption | 150 W |
