Mimosa A6 6 GHz PTMP Wireless Access Point
- SKU: 100-00113
$1,882.95 $1,999.00
- Manufacturer: Mimosa
- Data Sheet: Download
Product Information
The Mimosa A6 fixed wireless access point delivers up to 7 Gbps capacity, unbelievable subscriber capacity, and synchronized network scalability for unlicensed, outdoor, fixed wireless PTMP networks. The first future-proof solution that delivers fiber-fast gigabit speeds to subscribers via wireless, the A6 extends beyond the traditional 5 GHz bands to expand 160 MHz channels in the new, low-noise 6 GHz band.
Product Features:
- 10 Gigabit Ethernet: (2) SFP+ (optical) ports
- Management Services
- Smart Spectrum Management 8x8-MU-MIMO
- 5.150-6.425 GHz Extended Frequency
PoE Sold Separately
Specifications
Specifications 100-00113
| Performance | |
| Max Throughput | 7 Gbps IP aggregate UL/DL (9608 Mbps PHY) |
| Wireless Protocols | WiFi Interop; TDMA (future release) |
| Power | |
| Max Power Consumption | 40 W |
| System Power Method | Outdoor PoE or DC |
| System Lightning & ESD Protection | 6 kV |
| PoE Power Supply | Passive PoE compliant, 48–56 V (not included) |
| Radio | |
| MIMO & Modulation | 8x8 MU-MIMO; OFDMA, BPSK-1024QAM |
| Bandwidth | Single or dual 20/40/80/160 MHz channels |
| Frequency Range | 5150–6425 MHz Restricted by country of operation |
| Max Output Power | 29 dBm |
| Rx Sensitivity | @ 1024 QAM -47 dBm @ 160 MHz -50 dBm @ 80 MHz -53 dBm @ 40 MHz -56 dBm @ 20 MHz |
| Physical | |
| Dimensions | |
| Height | 490 mm (19”) |
| Width | 295 mm (11.6”) |
| Depth | 75 mm (3”) |
| Weight | 3.95 kg (8.7 lbs) |
| Enclosure Characteristics | Outdoor UV-stabilized, engineered polymer with integrated metal mounting back |
| Wind Survivability | 200 km/h (125 mph) |
| Wind Loading | 39 kg @ 160 km/h (86 lbs @ 100 mph) |
| Mounting | Dual standard pole straps for 30 mm (1.18”) to 90 mm (3.54”) OD pipes |
| Network Interface2 | (1) GbE copper PoE, (2) 10 GbE SFP+ (optical) |
| Environmental | |
| Outdoor Ingress Protection Rating | IP67 |
| Operating Temperature | -40°C to +55°C (-40°F to 131°F) |
| Operating Humidity | 5 to 100% condensing |
| Operating Altitude | 4,420 m (14,500’) maximum |
| Shock and Vibration | ETS 300-019-2-4 class 4M5 |
| Antenna | |
| Gain | 24 dBi with adaptive beamforming |
| Beamwidth | 90º azimuth, 7º elevation |
| Front-to-Back Ratio | >30 dB |
| Cross-Polar Isolation | >20 dB |
| Polarization | Dual-linear XPIC |
| Regulatory and Compliance | |
| Approvals | FCC Part 15.407; IC RSS210; CE (RED, EMCD, LVD, RoHS); ETSI 301 893/302 502 |
| RoHS Compliance | Yes |
| Safety | EN 62638-1 |
