Ubiquiti UISP airMAX NanoBeam 5AC Bridge (US)
- SKU: NBE-5AC-GEN2-US
$99.00
Product Information
Compact, UISP-ready, 5GHz WiFi bridge with enhanced surge protection and an optimized radio and antenna
Specifications
Specifications NBE‑5AC‑Gen2
| Dimensions (Mount Included) | 189 x 189 x 125 mm (7.44 x 7.44 x 4.92") |
| Weight (Mount Included) | 0.530 kg (1.17 lb) |
| Power Supply | 24V, 0.5A Gigabit PoE Adapter (Included) |
| Operating Frequency | Worldwide 2412 - 2472 MHz 5150 - 5875 MHz, USA: 2412 - 2462 MHz |
| Max. Power Consumption | 8.5W |
| Gain | 19 dBi |
| Networking Interface | (1) 10/100/1000 Ethernet Port Wi-Fi for Management |
| Processor Specs | Atheros MIPS 74Kc, 720 MHz |
| Memory | 128 MB DDR2, 8 MB Flash |
| LEDs | Power, Ethernet, (4) Signal Strength |
| Signal Strength LEDs | Software-Adjustable to Correspond to Custom RSSI Levels |
| Max. VSWR | 1.5:1 |
| Channel Sizes | PtP Mode 10/20/30/40/50/60/80 MHz PtMP Mode 10/20/30/40 MHz |
| Polarization | Dual Linear |
| Enclosure | Outdoor UV Stabilized Plastic |
| Mounting | Pole-Mount (Kit Included), Wall-Mount |
| Wind Loading | 45.4 N @ 200 km/h (10.2 lbf @ 125 mph) |
| Wind Survivability | 200 km/h (125 mph) |
| ESD/EMP Protection | Air: ± 24 kV, Contact: ± 24 kV |
| Operating Temperature | -40 to 80° C (-40 to 176° F) |
| Operating Humidity | 5 to 95% Noncondensing |
| Certifications | CE, FCC, IC |
| RoHS Compliance | Yes |
| Salt Fog Test | IEC 68-2-11 (ASTM B117), Equivalent: MIL-STD-810 G Method 509.5 |
| Vibration Test | IEC 68-2-6 |
| Temperature Shock Test | IEC 68-2-14 |
| UV Test | IEC 68-2-5 at 40° C (104° F), Equivalent: ETS 300 019-1-4 |
| Wind-Driven Rain Test | ETS 300 019-1-4, Equivalent: MIL-STD-810 G Method 506.5 |
