Ubiquiti Networks UniFi Premium Patch Cable
- SKU: UniFi Premium Patch Cable
$4.99 to $99.00Select options
- Manufacturer: Ubiquiti Networks
Product Information
Ubiquiti Networks UniFi Premium Patch Cable Indoor
Ultra-thin braided shielded RJ45 patch cable, designed and optimized for 10 GbE networking.
Features:
- Translucent booted RJ45 for optimal Etherlighting™ brightness
- 3 mm outer diameter for 0.15-8 m lengths
- 3.3 mm outer diameter for 12-15 m lengths
- Length: 0.15 to 15 m
Ubiquiti Networks UniFi Premium Patch Cable Outdoor
Ultra-thin, rugged, shielded outdoor patch cable, designed and optimized to perform in the harshest environments for 10 GbE networking.
Features:
- Shielded RJ45
- Insulated, weatherproof jacket
- Internal foil shielding and drain wire for increased ESD damage protection
- 3.5 mm outer diameter for 1-8 m lengths
- 3.9 mm outer diameter for 12-15 m lengths
- Length: 1 to 15 m
Specifications
Specifications - UniFi Premium Patch Cable Indoor
| Cable length | 0.15, 0.3, 1, 2, 3, 5, 8, 12, 15 m (from end-to-end) (0.5, 1, 3.3, 6.6, 9.8, 16.4, 26.2, 39.8, 49.2 ft) |
| Cable color | White |
| Jacket diameter | 0.15-8 m: 3 mm (0.11") 12-15 m: 3.3 mm (0.13") |
| Cable jacket | Braided |
| Cable type | Category 6A |
| Connector | (2) Translucent booted and shielding RJ45 |
| Supported data rate | Up to 10 GbE |
| Supported PoE type | Up to PoE+++ |
| Environment | Indoor |
| Standards | TIA-586-B.2 |
| Flame rating | VW-1 (UL1581) |
| Pack type | Single unit 24-pack (0.15 m) |
Specifications - UniFi Premium Patch Cable Outdoor
| Cable length | 1, 2, 3, 5, 8, 12, 15 m (from end-to-end) (3.3, 6.6, 9.8, 16.4, 26.2, 39.8, 49.2 ft) |
| Cable color | White |
| Cable material | Thermoplastic elastomer (TPE) |
| Jacket diameter | 1-8 m: 3.5 mm (0.14") 12-15 m: 3.9 mm (0.15") |
| Bend radius | 1-8 m: 28 mm (1.1") 12-15 m: 31 mm (1.2") |
| Connector | (2) Frosted booted and shielding RJ45 |
| Anti-crosstalk divider | Aluminum foil |
| Supported data rate | Up to 10 GbE |
| Supported PoE type | Up to PoE+++ |
| Environment | Outdoor |
| Standards | TIA/EIA-568-B.2 ISO/IEC 11801 |
| Flame rating | VW-1 (UL1581) |
| UV resistance | ISO4892-2 |
| Storage temperature | -40 to 85°C (-40 to 185°F) |
| Installation temperature | -20 to 60°C (-4 to 140°F) |
| Ambient operating temperature | -20 to 60°C (-4 to 140°F) |
