MikroTik RouterBOARD 922UAGS-5HPacD (US)
- SKU: RB922UAGS-5HPacD-US
Product Information
ISP Supplies supplies the MikroTik RouterBOARD 922UAGS-5HPacD (US) with 720Mhz CPU, 128MB RAM, 1xGigabit Ethernet, 1xSFP cage, 1xminiPCI-e, 1xSIM, onboard 802.11ac two Chain 5Ghz wireless, and RouterOS L4.
RouterBOARD RB922UAGS-5HPacD is a very versatile wireless router, perfect for assembling your own solution. It supports the new 802.11ac standard for high speed wireless (up to 866Mbit datarate and 20/40/80MHz channels). The device has ports and slots for many uses: 1x SFP cage, miniPCIe slot with SIM for 3G/4G modem or another wireless card, USB port, Gigabit Ethernet port and two MMCX connectors for the built in powerful 802.11ac 2x2 radio. Comes with RouterOS L4 (AP) license.
This version, RB922UAGS-5HPacD-US (USA) is factory locked for 5170-5250MHz and 5725-5835MHz frequencies. This lock can not be removed.
Specifications
Specifications RB922UAGS-5HPacD-US
| CPU nominal frequency | 720 MHz |
| CPU core count | 1 |
| Size of RAM | 128 MB |
| 10/100/1000 Ethernet ports | 1 |
| MiniPCI-e slots | 1 |
| Wireless standards | 802.11a/n/ac |
| Wireless chip model | QCA9882 |
| Number of USB ports | 1 |
| Power Jack | 1 |
| Supported input voltage | 8 V - 30 V |
| PoE in | Yes |
| Dimensions | 105x105mm |
| Operating System | RouterOS |
| Tested ambient temperature | -40°C .. +70°C tested |
| License level | 4 |
| CPU | QCA9557 |
| USB slot type | USB type A |
| Number of chains | 2 |
| Storage size | 128 MB |
| Storage type | NAND |
