MikroTik Outdoor PoE Router with 7x GbE / 1x 2.5GbE / 10G SFP+
- SKU: RB5009UPr+S+OUT
Product Information
An outdoor version to the best-selling RB5009 Series heavy-duty PoE router. The brand new RB5009UPr+S+OUT is a compact, cost-effective solution that will revolutionize your network tower setups. Like the indoor version, this RB5009 has 7x Gigabit Ethernet ports, one 2.5 Gigabit Ethernet port, a 10G SFP+ cage, and a full sized USB3 port!
This unit offers 9 possible ways of powering. There’s a 2-pin power connector on the front, as well as PoE-in and PoE-out on all eight Ethernet ports. The board can use any of these sources to power itself, choosing the one with the highest voltage when multiple sources are available. RB5009 takes up to 21W to power itself. If you’re using PoE-in, the board will stay on even if 8 of your 9 power sources suddenly go down. Unprecedented redundancy!
Each PoE-out port can supply up to 25W of power. All the ports combined are limited to 130W, which should be enough for most setups. (Note that the included PSU is capable of 96W total, so for maximum output, a different PSU will be needed). You can specify maximum available power from your power sources manually, if necessary. If you’re using PoE-out to power other devices, you have to provide power via the 2-pin connector to power those. This product also features single voltage PoE-out - it can either be 802.3at/af compatible or low-voltage PoE-out.
Product Features
- PoE-in and PoE-out on all ports
- 1x 2.5GbE, 7x GbE, 10G SFP+ ports
- 9 powering options
- 1GB DDR4 RAM
- 1GB NAND
- RouterOS v7
- IP66 Waterproof
Product Includes
- Hose clamp
- K-41 fastening set
- K-85 fastening set
Specifications
Specifications RB5009UPr+S+OUT
| CPU | Quad-Core 88F7040 1.4 GHz |
| CPU architecture | ARM 64bit |
| Size of RAM | 1 GB |
| RAM type | DDR4 |
| Storage | 1 GB, NAND |
| Number of 1G Ethernet ports | 7 |
| Number of 2.5G Ethernet ports | 1 |
| Number of 10G SFP+ ports | 1 |
| USB | 1 USB 3 type A |
| Operating system | RouterOS v7, License level 5 |
| Switch chip model | 88E6393 |
| Dimensions | 222 x 239 x 57 mm 8.74 x 9.40 x 2.24 inches |
| Operating temperature | -40°C to +70°C |
| Powering | |
| PoE-in | 802.3af/at |
| PoE-Out | 802.3af/at Same voltage as supplied via 2-pin terminal - Passive PoE or 802.3af/at Compatible (if 44–57V PSU used) |
| PoE-Out ports | Ether1 - Ether8, max out per port output (input < 30 V): 620 mA, max out per port output (input > 30 V): 420 mA |
| Smart PoE | Controller |
| Max total out | 2.59 A |
| Total output power | 130 W |
| Total output current | 2.28 A |
| Number of DC inputs | 2 |
| Supported input voltage | 24-57 V (PoE in) 24-57 (2-pin terminal) |
| Max power consumption (without attachments) | 15 W |
| Max power consumption | 150 W |
