Ubiquiti UniFi Enterprise 48-Port PoE L2 Switch
- SKU: USW-Enterprise-48-PoE
$1,599.00
+ $94.00 Surcharge
Product Information
A 48-port, Layer 3 switch with 2.5 GbE PoE+ output.
Specifications
Specifications USW-Enterprise-48-PoE
| Mechanical | |
| Dimensions | 442 x 44 x 400 mm (17.4 x 1.7 x 15.7") |
| Weight | Without Mount:6.2 kg (13.67 lb) |
| With Mount | 6.3 kg (13.89 lb) |
| Enclosure Material | SGCC Steel |
| Mount Material | SGCC Steel |
| Hardware | |
| Total Non-Blocking Throughput | 160 Gbps |
| Switching Capacity | 320 Gbps |
| Forwarding Rate | 238.095 Mpps |
| Max Power Consumption (Excluding PoE Output) | 150W |
| Power Method | (1) Universal AC input, 100-240VAC, 10A Max, 50/60 Hz (1) USP-RPS DC input, 52VDC, 13.84A; 11.5VDC, 13A |
| Power Supply | AC/DC, Internal, 100-240V, 10A Max. |
| Management Interface | Ethernet In-Band |
| Networking Interfaces | (48) 100MbE/1GbE/2.5GbE RJ45 port |
| SFP+ Interfaces | (4) 1/10G SFP+ ports |
| PoE Interfaces | (48) PoE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-) |
| Total Available PoE | 720W |
| Max. PoE+ Wattage per Port by PSE | 34.2W |
| Voltage Range 802.3af Mode | 44 to 57V |
| Voltage Range 802.3at Mode | 50 to 57V |
| Services | SMB Layer 3 PoE Gigabit Ethernet Switch |
| ESD/EMP Protection | Air:± 16 kV, Contact:± 12 kV |
| LCM Display | (1) 1.3" LCM color touchscreen |
| Bootup Animation | Bootup in Progress |
| Firmware Upgrade Icon | Firmware Upgrading |
| Steady White | Factory Defaults, Awaiting Adoption |
| Steady Blue | Device is Adopted |
| Button | Factory Reset |
| Operating Temperature | -5 to 40° C (23 to 104° F) |
| Operating Humidity | 10 - 90% Noncondensing |
| Certifications | CE, FCC, IC |
| LED | |
| Ethernet | White:Link or Activity |
| SFP+ | White:Link or Activity |
